| Model Number | 91043 |
| Product Description | Mammut 110 Ton Jack |
| Style | M100-40 |
| Capacity | 110 ton | 100 t |
| Net Weight | 370 lb | 168 kg |
| Working Air Pressure | 145-174 psi | 10-12 bar |
| Air Consumption | 600 nl/min |
| Max. Height | 23.7 in | 602 mm |
| Min Height | 15.7 in | 399 mm |
| Number of Pistons | 1 |
| Stroke | 8 in | 203 mm |
| Application | Mine and oil field, Construction site, Industrial assembly, Agricultural, Railway applications, Military |
| UPC | 816904025489 |
Mammut 110 Ton Jack
Model #91043
HIGH TONNAGE LOW-PROFILE AIR HYDRAULIC JACK (MODEL 91043)
The Mammut 110-Ton Low-Profile Air Hydraulic Jack delivers powerful lifting capability in a compact design, with a minimum height of 15.7 in. and a maximum height of 23.7 in. Engineered for applications requiring high tonnage and minimal clearance, this jack provides unmatched lifting performance while maintaining stability and safety.
1-Year Warranty.
Product Benefits
- Ultra low-profile design for limited clearance lifting applications.
- 110-ton capacity delivers extreme lifting power in compact form.
- Automatic piston return ensures efficient operation.
- Dual descent valves provide safe and controlled load handling.
- Remote control operation improves operator safety.
- Heavy-duty wheels and transport components for harsh environments.
Heavy Industrial Performance
MAMMUT air-hydraulic jacks are engineered as safe and efficient lifting solutions for the most demanding sectors including mining, construction, rail, aviation, port, and military industries. Featuring air-hydraulic operation, double descent valves, and automatic piston return, these jacks provide reliable performance, precise control, and durability in extreme working environments.
Key Features
110 TON CAPACITY
SINGLE-STAGE LOW-PROFILE DESIGN
15.7 IN. MIN HEIGHT
23.7 IN. MAX HEIGHT
Common Uses
Ideal for heavy-duty industrial equipment, mining machinery, construction vehicles, and applications where high tonnage must be combined with minimal ground clearance. Designed for environments where power, stability, and safety are critical.
MULTI-STAGE
1-YEAR WARRANTY
HEAVY DUTY BUILD
Accessories & Compatibility
Includes safety lock system, extension sets (3.125 in. to 11.875 in.), and tilting plate for adaptable lifting performance across industrial applications.
