| Model Number | 91004 |
| Product Description | Mammut 110 Ton Jack |
| Style | M100-72 |
| Capacity | 110 ton | 100 t |
| Net Weight | 626 lb | 284 kg |
| Working Air Pressure | 145-174 psi | 10-12 bar |
| Air Consuption | 600 nl/min |
| Max. Height | 46 in | 1170 mm |
| Min Height | 28.5 in | 725 mm |
| Number of Pistons | 1 |
| Stroke | 17.5 in | 445 mm |
| Application | Mine and oil field, Construction site, Industrial assembly, Agricultural, Railway applications, Military |
| UPC | 816904023591 |
MAMMUT 110 Ton Jack
Model #91004
SINGLE STAGE HIGH TONNAGE AIR HYDRAULIC JACK (MODEL 91004)
The Mammut High Tonnage Air Hydraulic Jack delivers 110 ton lifting capacity with an extended lifting range from 28.5 in. to 46 in. Designed for extreme-duty industrial environments, this single-stage jack provides exceptional lifting height, stability, and power for large-scale equipment applications.
1-Year Warranty.
Product Benefits
- Ultra high 110-ton capacity for extreme-duty lifting applications.
- Extended lifting range designed for tall and elevated equipment.
- Automatic piston return ensures smooth and consistent operation.
- Dual descent valves provide maximum safety and load control.
- Remote control operation enhances safety during lifting.
- Heavy-duty wheels and chassis designed for harsh environments.
Heavy Industrial Performance
MAMMUT air-hydraulic jacks are engineered for safe and efficient lifting across the most demanding industries, including mining, construction, rail, aviation, port, and military operations. Featuring air-hydraulic operation, double descent valves for improved safety, and automatic piston return, these jacks are designed for reliability in extreme working conditions.
Key Features
110 TON CAPACITY
SINGLE-STAGE HYDRAULIC DESIGN
28.5 IN. MIN HEIGHT
46 IN. MAX HEIGHT
Common Uses
Ideal for mining equipment, heavy construction machinery, quarry operations, and industrial applications requiring extreme lifting capacity and extended vertical reach. Built for environments where performance, safety, and durability are critical.
MULTI-STAGE
1-YEAR WARRANTY
HEAVY DUTY BUILD
Accessories & Compatibility
Includes heavy-duty extension sets, tilting plate, and safety lock system for secure and adaptable lifting configurations across large-scale industrial applications.
